1、For single phase motor, insulation resistance, DC resistance, AC withstand voltage, impulse withstand voltage, locked
rotor, no-load power, start and other electrical performance test items are completed automatically at one time, and the test
items can be selected freely.
2、The qualified standard can be set according to the requirements. If the test result data exceeds the standard, the
instrument will automatically alarm by sound and light, which is convenient and fast.
3、The DC low resistance test can detect the ambient temperature in real time, and the test results can be automatically
converted to the standard temperature value, which is more convenient to determine and ensure the consistency of the test.
4、Fast test speed is fast. The control core of the test instrument adopts ARM high-speed processor, and the data processing
is comprehensive and fast;
5、It can be built-in power supply to control the output of power supply to ensure the accuracy of power output;
6、Built in industrial computer, unlimited storage of test conditions and test results, USB storage interface, convenient data
copy, user-friendly operation interface, windows operating system, professional control software, simple and clear interface;
7、A variety of anti-interference measures are adopted, with strong anti-interference ability and hardware and software
protection, which greatly improves the reliability of the instrument.
